 Post subject: Unusual HMV 100 Portable
PostPosted: Tue Mar 03, 2015 4:09 pm
Offline
Victor III
Joined: Sun May 27, 2012 2:38 pm
Posts: 768
Location: United Kingdom
I recently bought this machine, which, at first glance appears to be standard HMV 100 portable. However, I've noticed that there are differences between this and all the other 100s I've seen. The most obvious is that the usual stays either side of the record pocket are not fitted. Instead, the covering material of the lid has been extended to form folded "hinges", which are fastened to the sides of the lid with small metal plates. The lid stay is on the left of the cabinet, whereas it is usually on the right, and the speed control, where it contacts the actuating lever that sticks through the motor board, is to the right of the lever, instead of the left, as in other versions. Note the rather cumbersome and fragile rest for the crook and soundbox, which was superceded by a simple pin on the crook, and a spring steel bar on the main part of the arm.

Does this mean, I wonder, that this is a very early version, and that the above differences were discontinued in favour of the usual equipment seen on the 100?

Barry


Attachments:
P1030296.JPG [ 126.21 KiB | Viewed 1830 times ]
P1030297.JPG [ 131.47 KiB | Viewed 1830 times ]
P1030295.JPG [ 127.13 KiB | Viewed 1830 times ]
P1030294.JPG [ 35.22 KiB | Viewed 1830 times ]
P1030293.JPG [ 88.26 KiB | Viewed 1830 times ]
P1030292.JPG [ 126.42 KiB | Viewed 1830 times ]
Top
 Profile

 Post subject: Re: Unusual HMV 100 Portable
PostPosted: Tue Mar 03, 2015 9:58 pm
Offline
Victor II
Joined: Fri Aug 01, 2014 8:59 pm
Posts: 345
the EMG colonel on youtube demonstrated the same differences between the earlier and later model 100 machines about a week ago

tino


Top
 Profile

 Post subject: Re: Unusual HMV 100 Portable
PostPosted: Wed Mar 04, 2015 4:32 pm
Offline
Victor III
Joined: Sun May 27, 2012 2:38 pm
Posts: 768
Location: United Kingdom
Dave Cooper states in his excellent book that in some cases, the 100 has a small black plate inside the case with a serial number on it. I just checked mine and it's there, with the number 1993. As the two Dave has examined were numbered 3705 and 15986, and the one pictured in the book is 4853, this must indeed be a very early machine. It would be interesting to find out how many were made before the modifications were carried out.

Barry


Top
 Profile

 Post subject: Re: Unusual HMV 100 Portable
PostPosted: Thu Mar 05, 2015 3:43 pm
Offline
Victor V
User avatar
Joined: Thu Jan 08, 2009 12:01 pm
Posts: 2259
Location: Allentown, Pennsylvania
That's a beautiful little machine, Barry. congratulations!

What is the function of the metal clip that I see at the back left corner, held by two screws?


Top
 Profile

 Post subject: Re: Unusual HMV 100 Portable
PostPosted: Thu Mar 05, 2015 5:41 pm
Offline
Victor III
Joined: Sun May 27, 2012 2:38 pm
Posts: 768
Location: United Kingdom
Thanks, Henry.
The clip is to hold the crook and soundbox. The whole arm raises from this position as it's moved towards the edge of the record, and lowers as it's pushed back towards the clip. They say a picture's worth a thousand words, so here you are:

Barry


Attachments:
P1030298.JPG [ 137.81 KiB | Viewed 1689 times ]
Top
 Profile

 Post subject: Re: Unusual HMV 100 Portable
PostPosted: Fri Mar 06, 2015 10:28 am
Offline
Victor V
User avatar
Joined: Thu Jan 08, 2009 12:01 pm
Posts: 2259
Location: Allentown, Pennsylvania
Aha! Thanks for the visual clarification. I see that you did refer to this in your original post, but I failed to apprehend. (Or comprehend. Or reprehend. Or one o' them thar -prehends!)


Top
 Profile

 Post subject: Re: Unusual HMV 100 Portable
PostPosted: Fri Mar 06, 2015 3:27 pm
Offline
Victor III
Joined: Sun May 27, 2012 2:38 pm
Posts: 768
Location: United Kingdom
No, you didn't fail to comprehend! The one I was referring to in the original post was the one just behind the joint between the main arm and the crook, that the soundbox rests on between records. (first photo). It was missing when I bought the machine, and a fellow collector kindly sent me details of an original, so I was able to make one from a piece of broken mainspring!

Barry


Top
 Profile

 Post subject: Re: Unusual HMV 100 Portable
PostPosted: Wed Mar 11, 2015 5:05 am
Offline
Victor III
User avatar
F. Depero, "Grammofono", 1923.
Joined: Thu Feb 24, 2011 4:19 am
Posts: 847
Location: Italy
Thanks for posting, Barry, that was very interesting!

I also own a 100 (a "normal" variation) and I literally love this machine. Although geometry and acoustics are only so and so, the goose neck / tapered arm combo is a marvel to look at, and the turn-to-raise mechanism is just awesome. Also, the motor is very powerful (at least, mine is) and it performs superbly even on records where usually all other portables fail. 8-)

You did a great job with the arm stand: I wouldn't have figured it was made with scraps, hadn't you told us. :geek:


Top
 Profile

 Post subject: Re: Unusual HMV 100 Portable
PostPosted: Wed Mar 11, 2015 8:06 am
Offline
Victor III
Joined: Sun May 27, 2012 2:38 pm
Posts: 768
Location: United Kingdom
Thanks for the kind comments, Marco.

When I bought it on eBay, I hadn't noticed the differences between this and the "standard" model. It was only when I decided to give it an overhaul that they became apparent. Information about the very early models is hard to find, but if anything does turn up, I'll post it on the forum.

Barry


Top
 Profile

 Post subject: Re: Unusual HMV 100 Portable
PostPosted: Sun Apr 28, 2019 1:50 pm
Offline
Victor III
User avatar
floating down stream ...
Joined: Tue Feb 20, 2018 12:52 pm
Posts: 583
Location: Made it, Ma ! Top of the world !
Phono48 wrote:
Dave Cooper states in his excellent book that in some cases, the 100 has a small black plate inside the case with a serial number on it. I just checked mine and it's there, with the number 1993. As the two Dave has examined were numbered 3705 and 15986, and the one pictured in the book is 4853, this must indeed be a very early machine. It would be interesting to find out how many were made before the modifications were carried out.

Barry


I hope it is okay to revive this thread.

I found it so very interesting that I recently bought an HMV 100.

You mentioned "It would be interesting to find out how many were made before the modifications were carried out".

I was very surprised to see that mine seems to be quite a late production number but has some parts which seem to be from the 'initial left hand side hinge production' model and some from the later 'right hand side hinge' model.

I assume therefore that the older parts were used up and slowly but surely the 100's were produced entirely with the new ones.

But there seems to be a long gap (period of time) between your number 1993 and my number 7382 - which surprised me.

Anyway, my machine seems to have the older version speed control, turntable and motor setup. Maybe the latch /catch too? Very sadly the winding escutcheon has disappeared - so that is unknown. (Photo's below').

The 'new' features are the metal hinged record storage and lid hinge is on the right hand side.

I didn't understand the comments about 'The clip holding the crook and soundbox' - but include a photo below in case this indicates new or old parts stock.

So, mine appears to be partly old parts and partly new parts ?


Attachments:
oldversion setup.jpg
oldversion setup.jpg [ 213.38 KiB | Viewed 438 times ]
oldpartturntable.jpg [ 309.18 KiB | Viewed 438 times ]
oldlatch.jpg [ 297.12 KiB | Viewed 438 times ]
old versionspeedcontrol.jpg
old versionspeedcontrol.jpg [ 303.81 KiB | Viewed 438 times ]
newversionstorage.jpg [ 219.38 KiB | Viewed 438 times ]
missing.jpg [ 267.93 KiB | Viewed 438 times ]
clip.jpg [ 226.61 KiB | Viewed 438 times ]
100number.jpg [ 306.27 KiB | Viewed 438 times ]
