Victrola the Fourteenth

Post by mrbechet »

I just got VV-XIV #248717 for $100 and it’s turning out to be a project. Spring 1 is broken and the rest were pretty much glued in place. (Didn’t have to worry about whether I was removing them still wound up!)

Given that one spring is broken and one bent at the pear-shaped hole, do I need to replace one, two, or all four?

Thanks all!
Mark
Attachments
Top
User avatar
gramophone-georg
Victor Monarch
Posts: 4327
Joined: Mon Jan 20, 2014 11:55 pm
Personal Text: Northwest Of Normal
Location: Eugene/ Springfield Oregon USA

Re: Victrola the Fourteenth

Post by gramophone-georg »

In my opinion- if you want it right and trouble- free, replacing all 4 is the only correct answer. Replace the governor springs while you are at it.
"He who dies with the most shellac wins"- some nutty record geek

I got PTSD from Peter F's avatar
Top
VanEpsFan1914
Victor VI
Posts: 3343
Joined: Fri Oct 06, 2017 11:39 am
Personal Text: I've got both kinds of music--classical & rag-time.
Location: South Carolina

Re: Victrola the Fourteenth

Post by VanEpsFan1914 »

Seconding the George recommendation for new springs. I have an XIV with the older three-spring motor, and when I first did it I put one old recycled spring in to replace one that was cracked. When I opened it for new grease eight years later it had cracked the other spring. Fresh mainsprings on all three barrels and it works pretty well! Much smoother winding and unwinding.

Charles
